69958 Series

Catalog

CONN HEADER R/A 8POS 2.54MM

Part	Pitch - Mating	Pitch - Mating	Style	Connector Type	Contact Material	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Post	Contact Length - Post	Contact Finish - Mating	Number of Positions Loaded	Termination	Features	Number of Rows	Insulation Height	Insulation Height	Contact Shape	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Fastening Type	Material Flammability Rating	Contact Type	Insulation Material	Shrouding	Mounting Type	Current Rating (Amps)
Amphenol ICC (FCI) 69958-104LF	0.1 in	2.54 mm	Board to Cable/Wire	Header	Copper Alloy	2.54 mm	0.1 in	0.13 in	3.3 mm	Gold or Gold GXT™	All	Solder	Board Guide Ground Pin	2	0.525 in	13.34 mm	Square	Black	30 Áin	0.76 Ám	8	Latch Holder	UL94 V-0	Male Pin	Thermoplastic	Shrouded - 4 Wall	Through Hole Right Angle	2.5 A
Amphenol ICC (FCI) 69958-104MLF	0.1 in	2.54 mm	Board to Cable/Wire	Header	Copper Alloy	2.54 mm	0.1 in	0.13 in	3.3 mm	Gold or Gold GXT™	All	Solder	Board Guide Ground Pin	2	0.525 in	13.34 mm	Square	Black	30 Áin	0.76 Ám	8	Latch Holder	UL94 V-0	Male Pin	Thermoplastic	Shrouded - 4 Wall	Through Hole Right Angle	2.5 A
Amphenol ICC (FCI) 69958-102LF	0.1 in	2.54 mm	Board to Cable/Wire	Header	Copper Alloy	2.54 mm	0.1 in	0.13 in	3.3 mm	Gold or Gold GXT™	All	Solder	Board Guide Ground Pin	2	0.525 in	13.34 mm	Square	White	30 Áin	0.76 Ám	8	Latch Holder	UL94 V-0	Male Pin	Thermoplastic	Shrouded - 4 Wall	Through Hole Right Angle	2.5 A
Amphenol ICC (FCI) 69958-107LF	0.1 in	2.54 mm	Board to Cable/Wire	Header	Copper Alloy	2.54 mm	0.1 in	0.13 in	3.3 mm	Gold or Gold GXT™	All	Solder	Board Guide Ground Pin	2	0.525 in	13.34 mm	Square	Gray	30 Áin	0.76 Ám	8	Latch Holder	UL94 V-0	Male Pin	Thermoplastic	Shrouded - 4 Wall	Through Hole Right Angle	2.5 A
