PBC22 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 44POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Connector Type	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Material Flammability Rating	Fastening Type	Number of Rows [custom]	Contact Length - Post [custom]	Contact Length - Post [custom]	Contact Type	Insulation Height [z]	Insulation Height [z]	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Contact Shape	Contact Material	Style	Shrouding	Insulation Material	Contact Length - Mating	Contact Length - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Current Rating (Amps)	Insulation Color	Contact Finish - Mating	Number of Positions	Insulation Height	Insulation Height	Number of Rows	Contact Length - Post	Contact Length - Post	Overall Contact Length	Overall Contact Length	Overall Contact Length
Sullins Connector Solutions PBC22DBBN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin	0.1 in	2.54 mm	UL94 V-0	Push-Pull	2	5.08 mm	0.2 "	Male Pin	6.1 mm	0.24 in	Solder	-65 ░C	125 °C	Right Angle Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.23 in	5.84 mm	0.25 µm	10 µin	All	3 A	Black	Gold	44
Sullins Connector Solutions PBC22SBBN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin			UL94 V-0	Push-Pull		5.08 mm	0.2 "	Male Pin			Solder	-65 ░C	125 °C	Right Angle Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.23 in	5.84 mm	0.25 µm	10 µin	All	3 A	Black	Gold	22	3.56 mm	0.14 in	1
Sullins Connector Solutions PBC22DGAN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin	0.1 in	2.54 mm	UL94 V-0	Push-Pull	2			Male Pin	6.1 mm	0.24 in	Solder	-65 ░C	125 °C	Right Angle Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.318 in	8.08 mm	0.25 µm	10 µin	All	3 A	Black	Gold	44				0.1 in	2.54 mm
Sullins Connector Solutions PBC22SBDN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin			UL94 V-0	Push-Pull				Male Pin			Solder	-65 ░C	125 °C	Right Angle Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.23 in	5.84 mm	0.25 µm	10 µin	All	3 A	Black	Gold	22	3.56 mm	0.14 in	1	0.4 in	10.16 mm
Sullins Connector Solutions PBC22DAEN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin	0.1 in	2.54 mm	UL94 V-0	Push-Pull	2			Male Pin			Solder	-65 ░C	125 °C	Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.23 in	5.84 mm	0.25 µm	10 µin	All	3 A	Black	Gold	44	2.54 mm	0.1 in		0.52 in	13.21 mm	0.85 in	21.59 mm
Sullins Connector Solutions PBC22SAFN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin			UL94 V-0	Push-Pull		15.75 mm	0.62 "	Male Pin			Solder	-65 ░C	125 °C	Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.23 in	5.84 mm	0.25 µm	10 µin	All	3 A	Black	Gold	22	2.54 mm	0.1 in	1			0.95 in	24.13 mm
Sullins Connector Solutions PBC22SFCN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin			UL94 V-0	Push-Pull				Male Pin			Solder	-65 ░C	125 °C	Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.318 in	8.08 mm	0.25 µm	10 µin	All	3 A	Black	Gold	22	2.54 mm	0.1 in	1	0.32 in	8.13 mm		18.75 mm	0.738 in
Sullins Connector Solutions PBC22DFCN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin	0.1 in	2.54 mm	UL94 V-0	Push-Pull	2			Male Pin			Solder	-65 ░C	125 °C	Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.318 in	8.08 mm	0.25 µm	10 µin	All	3 A	Black	Gold	44	2.54 mm	0.1 in		0.32 in	8.13 mm		18.75 mm	0.738 in
Sullins Connector Solutions PBC22SGBN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin			UL94 V-0	Push-Pull		5.08 mm	0.2 "	Male Pin			Solder	-65 ░C	125 °C	Right Angle Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.318 in	8.08 mm	0.25 µm	10 µin	All	3 A	Black	Gold	22	3.56 mm	0.14 in	1
Sullins Connector Solutions PBC22SBEN	2.54 µm	100 µin	Header Breakaway	0.1 "	2.54 mm	Tin			UL94 V-0	Push-Pull				Male Pin			Solder	-65 ░C	125 °C	Right Angle Through Hole	Square	Phosphor Bronze	Board to Board Cable	Unshrouded	Polybutylene Terephthalate (PBT)	0.23 in	5.84 mm	0.25 µm	10 µin	All	3 A	Black	Gold	22	3.56 mm	0.14 in	1	0.5 "	12.7 mm
