MKS2P Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
RELAY GEN PURPOSE DPDT 10A 240V
| Part | Mounting Type | Must Operate Voltage | Contact Rating (Current) | Operate Time | Coil Current | Load - Max Switching | Relay Type | Approval Agency | Contact Form | Coil Resistance | Coil Type | Operating Temperature [Min] | Operating Temperature [Max] | Switching Voltage [Max] | Coil Voltage | Must Release Voltage | Release Time | Contact Material | Termination Style | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | Socketable | 192 VAC | 10 A | 20 ms | 9.6 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 4.48 kOhms | Non Latching | -40 °C | 60 °C | 30 VDC 250 VAC | 240 VAC | 72 VAC/DC | 20 ms | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | |
 Omron Electronics Inc-EMC Div | Socketable | 19.2 VDC | 10 A | 30 ms | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 430 Ohms | Non Latching | -40 °C | 60 °C | 30 VDC 250 VAC | 24 VDC | 3.6 VDC | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Diode Mechanical Indicator Test Button | ||
Omron Electronics Inc-EMC Div | Socketable | 4.8 VDC | 10 A | 30 ms | 224 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 26.7 Ohms | Non Latching | -25 °C | 60 °C | 30 VDC 250 VAC | 0.9 VDC | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Diode Lighted Indicator | ||
Omron Electronics Inc-EMC Div | Socketable | 4.8 VAC/DC | 10 A | 20 ms | 385 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 3.1 Ohms | Non Latching | -25 °C | 60 °C | 30 VDC 250 VAC | 6 VAC | 1.8 VAC | 20 ms | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Lighted Indicator Mechanical Indicator Test Button Varistor |
Omron Electronics Inc-EMC Div | Socketable | 96 VAC | 10 A | 20 ms | 19.3 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 1130 Ohms | Non Latching | -25 °C | 60 °C | 30 VDC 250 VAC | 120 VAC | 36 VAC | 20 ms | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Lighted Indicator Varistor |
Omron Electronics Inc-EMC Div | Socketable | 38.4 VDC | 10 A | 30 ms | 28.1 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 1.71 kOhms | Non Latching | -40 °C | 60 °C | 30 VDC 250 VAC | 48 VDC | 7.2 VDC | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Diode Mechanical Indicator | |
Omron Electronics Inc-EMC Div | Socketable | 9.6 VDC | 10 A | 30 ms | 112 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 107 Ohms | Non Latching | -25 °C | 60 °C | 30 VDC 250 VAC | 12 VDC | 1.8 VDC | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Diode Lighted Indicator | |
 Omron Electronics Inc-EMC Div | Socketable | 184 VAC | 10 A | 20 ms | 10 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 4.25 kOhms | Non Latching | -25 °C | 60 °C | 30 VDC 250 VAC | 230 VAC | 69 VAC | 20 ms | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | |
Omron Electronics Inc-EMC Div | Socketable | 176 VAC | 10 A | 20 ms | 10.5 mA | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 3.55 kOhms | Non Latching | -40 °C | 60 °C | 30 VDC 250 VAC | 220 VAC/DC | 66 VAC | 20 ms | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) | Mechanical Indicator |
 Omron Electronics Inc-EMC Div | Socketable | 19.2 VDC | 10 A | 30 ms | 300 W 2500 VA | General Purpose | CSA cURus TUV | DPDT (2 Form C) | 430 Ohms | Non Latching | -25 °C | 60 °C | 30 VDC 250 VAC | 24 VDC | 3.6 VDC | 20 ms | Silver Tin Indium (AgSnIn) | Plug In 8 Pin (Octal) |
