2111 Series

Manufacturer: Oupiin

Catalog

PIN HEADER, DOUBLE ROW, 10 PIN,

Part	Contact Finish Thickness - Post	Contact Finish - Post	Number of Positions	Connector Type	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Insulation Color	Contact Material	Contact Finish Thickness - Mating	Insulation Height [z]	Insulation Height [z]	Fastening Type	Voltage Rating	Contact Length - Mating	Contact Length - Mating	Number of Rows [custom]	Contact Length - Post	Contact Length - Post	Insulation Material	Contact Shape	Pitch - Mating	Pitch - Mating	Shrouding	Termination	Row Spacing - Mating	Row Spacing - Mating	Mounting Type	Material Flammability Rating	Current Rating (Amps)	Contact Type	Number of Rows	Insulation Height	Insulation Height	Contact Length - Post [x]	Contact Length - Post [x]	Overall Contact Length	Overall Contact Length
Oupiin 2111-2X05G00RB	Flash	Gold	10	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash	4 mm	0.157 in	Push-Pull	125 VDC	3.7 mm	0.146 in	2	0.118 in	3 mm	Nylon 6T Polyamide (PA6T)	Square	0.079 "	2 mm	Unshrouded	Solder	2 mm	0.079 in	Right Angle Through Hole	UL94 V-0	2 A	Male Pin
Oupiin 2111-1X40G00S-3.7-6.4B	Flash	Gold	40	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	6.4 mm	0.252 in				Nylon 6T Nylon 9T Polyamide (PA6T) Polyamide (PA9T)	Square	0.079 "	2 mm	Unshrouded	Solder			Through Hole	UL94 V-0	2 A	Male Pin	1	0.059 in	1.5 mm	3.7 mm	0.146 "	11.6 mm	0.457 in
Oupiin 2111-1X03G00SB	Flash	Gold		Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in		0.118 in	3 mm	Nylon 6T Nylon 9T Polyamide (PA6T) Polyamide (PA9T)	Square	0.079 " 0.1 "	2 mm 2.54 mm	Unshrouded	Solder			Through Hole	UL94 V-0	2 A	Male Pin	1	0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-2X02G00SB	Flash	Gold	4	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in	2	0.118 in	3 mm	Nylon 6T Polyamide (PA6T)	Square	0.079 "	2 mm	Unshrouded	Solder	2 mm	0.079 in	Through Hole	UL94 V-0	2 A	Male Pin		0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-2X07G00SB	Flash	Gold	14	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in	2	0.118 in	3 mm	Nylon 6T Polyamide (PA6T)	Square	0.079 "	2 mm	Unshrouded	Solder	2 mm	0.079 in	Through Hole	UL94 V-0	2 A	Male Pin		0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-2X13G00SB	Flash	Gold	26	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in	2	0.118 in	3 mm	Nylon 6T Polyamide (PA6T)	Square	0.079 "	2 mm	Unshrouded	Solder	2 mm	0.079 in	Through Hole	UL94 V-0	2 A	Male Pin		0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-2X04G00SB	Flash	Gold	8	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in	2	0.118 in	3 mm	Nylon 6T Polyamide (PA6T)	Square	0.079 "	2 mm	Unshrouded	Solder	2 mm	0.079 in	Through Hole	UL94 V-0	2 A	Male Pin		0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-1X06G00SB	Flash	Gold	6	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in		0.118 in	3 mm	Nylon 6T Nylon 9T Polyamide (PA6T) Polyamide (PA9T)	Square	0.079 " 0.1 "	2 mm 2.54 mm	Unshrouded	Solder			Through Hole	UL94 V-0	2 A	Male Pin	1	0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-2X09G00SB	Flash	Gold	18	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.7 mm	0.146 in	2	0.118 in	3 mm	Nylon 6T Polyamide (PA6T)	Square	0.079 "	2 mm	Unshrouded	Solder	2 mm	0.079 in	Through Hole	UL94 V-0	2 A	Male Pin		0.059 in	1.5 mm			8.2 mm	0.323 in
Oupiin 2111-1X05G00S-3.5-3.2B	Flash	Gold	5	Header Header Cuttable	All	-40 C	105 ░C	Gold	Black	Brass	Flash			Push-Pull	125 VDC	3.2 mm 3.7 mm	0.126 in 0.146 in		0.118 in	3 mm	Nylon 6T Nylon 9T Polyamide (PA6T) Polyamide (PA9T)	Square	0.079 " 0.1 "	2 mm 2.54 mm	Unshrouded	Solder			Through Hole	UL94 V-0	2 A	Male Pin	1	0.059 in	1.5 mm			7.7 mm 8.2 mm	0.303 in 0.323 in
