857-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 42POS 0.156
| Part | Material - Insulation | Mounting Type | Termination | Termination Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Number of Positions/Bay/Row [custom] | Contact Material | Card Type | Number of Positions | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Read Out | Card Thickness [Max] | Card Thickness [Min] | Gender | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 1 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 1 | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 21 | Copper Alloy | Non Specified - Single Edge | 21 | 3.96 mm | 0.156 in | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Tin | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Tin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 1 | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 1 | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 1 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Through Hole | Solder Eyelet(s) | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Tin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 1 | Semi Bellows | 21 | Copper Alloy | Non Specified - Single Edge | 21 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 1 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Semi Bellows | 21 | Copper Alloy | Non Specified - Dual Edge | 42 | 2 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Semi Bellows | 21 | Copper Alloy | Non Specified - Single Edge | 21 | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Black | 125 °C | -40 C | Gold | 1 |
