RB550ASA-30FH Series

Low VF, 30V, 500mA, DFN1006-2W, Schottky Barrier Diode for Automotive

Catalog

Low VF, 30V, 500mA, DFN1006-2W, Schottky Barrier Diode for Automotive

Part	Speed	Qualification	Voltage - Forward (Vf) (Max) @ If	Operating Temperature - Junction	Mounting Type	Current - Average Rectified (Io)	Package / Case	Grade	Voltage - DC Reverse (Vr) (Max) [Max]	Current - Reverse Leakage @ Vr	Technology
Rohm Semiconductor RB550ASA-30FHT2RB	200 mA 500 ns	AEC-Q101	590 mV	150 ¯C	Surface Mount Wettable Flank	500 mA	SOD-882	Automotive	30 V	35 µA	Schottky

Catalog

Low VF, 30V, 500mA, DFN1006-2W, Schottky Barrier Diode for Automotive

Description

RB550ASA-30FH is low VFand high reliability Schottky Barrier Diode, suitable for general rectification. It is a highly reliable product for automotive.
