Pch -20V -3A Small Signal MOSFET for Automotive
Description
AI
RTR030P02HZG is a low on-resistance MOSFET for automotive, suitable for switching applications.
Beta
⌘K
Pch -20V -3A Small Signal MOSFET for Automotive
Pch -20V -3A Small Signal MOSFET for Automotive
| Part | Supplier Device Package | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Drive Voltage (Max Rds On, Min Rds On) [Max] | Drive Voltage (Max Rds On, Min Rds On) [Min] | Grade | FET Type | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | Gate Charge (Qg) (Max) @ Vgs [Max] | Power Dissipation (Max) [Max] | Operating Temperature | Technology | Mounting Type | Package / Case | Qualification | Vgs(th) (Max) @ Id | Drain to Source Voltage (Vdss) | Input Capacitance (Ciss) (Max) @ Vds [Max] | Gate Charge (Qg) (Max) @ Vgs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | TSMT3 | 3 A | 67 mOhm | 2.5 V | 4.5 V | Automotive | N-Channel | 12 V | 510 pF | 6.2 nC | 700 mW | 150 °C | MOSFET (Metal Oxide) | Surface Mount | SC-96 | AEC-Q101 | 1.5 V | 45 V | ||
 Rohm Semiconductor | TSMT3 | 3 A | 75 mOhm | 2.5 V | 4.5 V | Automotive | P-Channel | 12 V | 700 mW | 150 °C | MOSFET (Metal Oxide) | Surface Mount | SC-96 | AEC-Q101 | 2 V | 20 V | 840 pF | 9.3 nC |
