Schaffner FN9233 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

Catalog

PWR ENT RCPT IEC320-C14 PANEL QC

...

Part	Connector Type	Material Flammability Rating	Connector Style	Current Rating - Filter	Mounting Type	Termination	Termination	Termination	Filter Type	Approval Agency	Panel Thickness [Max]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Min]	Accomodates a Fuse	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Ingress Protection	Features
TE Connectivity AMP Connectors FN9233S1R-12-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	12 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		28.5 mm	21.9 mm	IP40	Bleed Resistor
TE Connectivity AMP Connectors FN9233ES-3-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	3 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		29.4 mm	20.8 mm	IP40	Earth Line Choke
TE Connectivity AMP Connectors FN9233ES1B-3-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	3 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial Medical	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		28.5 mm	21.9 mm	IP40	Bleed Resistor Earth Line Choke
TE Connectivity AMP Connectors FN9233S-8-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	8 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		29.4 mm	20.8 mm	IP40
TE Connectivity AMP Connectors FN9233ES1B-6-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	6 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial Medical	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		28.5 mm	21.9 mm	IP40	Bleed Resistor Earth Line Choke
TE Connectivity AMP Connectors FN9233SR-3-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	3 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		29.4 mm	20.8 mm	IP40	Bleed Resistor
TE Connectivity AMP Connectors FN9233U-6-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	6 A	Flange Panel Mount	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL								IP40	Front or Rear Side Mount
TE Connectivity AMP Connectors FN9233R-1-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	1 A	Flange Panel Mount	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL								IP40	Bleed Resistor Front or Rear Side Mount
TE Connectivity AMP Connectors FN9233UB-12-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	12 A	Flange Panel Mount	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL								IP40	Front or Rear Side Mount
TE Connectivity AMP Connectors FN9233ESR-6-06	Receptacle Male Blades	UL94 V-2	IEC 320-C14	6 A	Panel Mount Snap-In	6.3 mm	Quick Connect	0.25 "	Filtered (EMI RFI) - Commercial	CQC CSA ENEC UL	0.059 in	1.5 mm	0.028 in	0.7 mm		29.4 mm	20.8 mm	IP40	Bleed Resistor Earth Line Choke
