896-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 12POS 0.125
| Part | Termination Rows | Material - Insulation | Gender | Read Out | Contact Finish | Termination | Card Type | Pitch | Pitch | Contact Type | Number of Positions | Number of Positions/Bay/Row | Mounting Type | Number of Rows | Color | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Single | Gold | Solder Eyelet(s) | Non Specified - Single Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 12 | Through Hole | 1 | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 125 °C | -40 C | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Dual | Gold | Solder | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 6 | Through Hole | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | 125 °C | -40 C | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Dual | Gold | Wire Wrap | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 6 | Through Hole | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 125 °C | -40 C | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Dual | Gold | Wire Wrap | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 6 | Through Hole | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 2 | 2 | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Single | Gold | Solder | Non Specified - Single Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 12 | Right Angle Through Hole | 1 | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Single | Gold | Solder | Non Specified - Single Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 12 | Through Hole | 1 | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | 125 °C | -40 C | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Dual | Gold | Wire Wrap | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 6 | Through Hole | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Female | Single | Gold | Solder | Non Specified - Single Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 12 | Through Hole | 1 | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 125 °C | -40 C | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Dual | Gold | Solder | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 6 | Right Angle Through Hole | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | 125 °C | -40 C | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Dual | Gold | Solder Eyelet(s) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Cantilever | 12 | 6 | Through Hole | Black | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 125 °C | -40 C | 2 | 2 |
