RJMG1 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN JACK 1PORT 100 BASE-T PCB
| Part | Shield Material | Housing Material | Contact Finish Thickness | Features | Contact Finish | Tab Direction | Orientation | Connector Type | Number of Ports | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Height Above Board [z] | Height Above Board | Contact Material | Termination | Number of Rows | Mounting Type | Applications | LED Color | Contact Finish Thickness | Contact Finish Thickness | Height Above Board | Number of Cores per Jack |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Stainless Steel | Polyamide (PA) Nylon | Flash | Board Lock | Gold | Down | 90 ° | RJ45 | 1 | EMI Finger Shielded | 70 °C | 0 °C | 0.526 in | 13.36 mm | Phosphor Bronze | Solder | 1 | Through Hole | 10/100 Base-T AutoMDIX | Yellow - Green | ||||
 Amphenol ICC (Commercial Products) | ||||||||||||||||||||||||
 Amphenol ICC (Commercial Products) | Stainless Steel | Polyamide (PA) Nylon | Board Lock | Gold | Up | 90 ° | RJ45 | 1 | EMI Finger Shielded | 70 °C | 0 °C | 13.49 mm | Phosphor Bronze | Solder | 1 | Through Hole | 10/100 Base-T AutoMDIX | Yellow - Green | 30 Áin | 0.76 Ám | 0.531 in | 6 |
