1804A Series
Manufacturer: Belden Inc.
Beta
⌘K
4 #28 STR PP SHLD PVC
| Part | Shield Coverage | Shield Material | Jacket (Insulation) Material | Cable Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Shield Type | Wire Gauge | Operating Temperature [Min] | Operating Temperature [Max] | Usage | Number of Conductors | Voltage | Conductor Insulation | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Conductor Material | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 80 % | Copper Tinned | Poly-Vinyl Chloride (PVC) | Microphone | 0.014 in | 0.356 mm | Braid | 28 AWG | -30 ░C | 60 °C | Audio | 4 | 100 V | Polypropylene (PP) | 40 AWG | 19 | 2.92 mm | 0.115 in | Beige | Copper Alloy Silver Coated | 152.4 m | 500 ft |
