794594 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN PLUG HSG 2POS 94V
| Part | Contact Type | Note | Color | Operating Temperature [Min] | Operating Temperature [Max] | Row Spacing | Row Spacing | Number of Positions | Contact Termination | Number of Rows [custom] | Fastening Type | Insulation Material | Mounting Type | Connector Type | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors | Male Pin | Contacts Not Included | White | -55 C | 105 ░C | 0.165 in | 4.2 mm | 2 | Crimp | 2 | Locking Ramp | Nylon Polyamide (PA) | Free Hanging (In-Line) | Plug | ||
 TE Connectivity AMP Connectors | Male Pin | Contacts Not Included | White | 0.165 in | 4.2 mm | 8 | Crimp | 2 | Locking Ramp | Free Hanging (In-Line) | Plug | 0.165 in | 4.2 mm | |||
TE Connectivity AMP Connectors | Male Pin | Contacts Not Included | White | 0.165 in | 4.2 mm | 24 | Crimp | 2 | Locking Ramp | Free Hanging (In-Line) | Plug | 0.165 in | 4.2 mm | |||
 TE Connectivity AMP Connectors | Male Pin | Contacts Not Included | White | 0.165 in | 4.2 mm | 4 | Crimp | 2 | Locking Ramp | Free Hanging (In-Line) | Plug | 0.165 in | 4.2 mm |
