PEC24 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER VERT 24POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Material Flammability Rating	Connector Type	Insulation Material	Contact Length - Mating	Contact Length - Mating	Current Rating (Amps)	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Mounting Type	Insulation Height	Insulation Height	Contact Length - Post	Contact Length - Post	Contact Shape	Overall Contact Length [x]	Overall Contact Length [x]	Number of Rows	Pitch - Mating	Pitch - Mating	Contact Type	Shrouding	Contact Material	Fastening Type	Style	Termination	Contact Finish - Post	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Rows [custom]	Overall Contact Length	Overall Contact Length	Insulation Height [z]	Insulation Height [z]	Contact Length - Post [custom]	Contact Length - Post [custom]
Sullins Connector Solutions PEC24SFAN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	8.08 mm	0.318 in	3 A	All	-65 ░C	125 °C	24	Through Hole	0.1 in	2.54 mm	3.05 mm	0.12 in	Square	13.67 mm	0.538 in	1	0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm
Sullins Connector Solutions PEC24DADN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	48	Through Hole	0.1 in	2.54 mm	10.67 mm	0.42 in	Square	19.05 mm	0.75 in		0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm	0.1 in	2.54 mm	2
Sullins Connector Solutions PEC24DAHN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	48	Through Hole	0.1 in	2.54 mm	20.83 mm	0.82 in	Square				0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm	0.1 in	2.54 mm	2	29.21 mm	1.15 in
Sullins Connector Solutions PEC24SAHN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	24	Through Hole	0.1 in	2.54 mm	20.83 mm	0.82 in	Square			1	0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm				29.21 mm	1.15 in
Sullins Connector Solutions PEC24DBAN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	48	Right Angle Through Hole			2.54 mm	0.1 in	Square				0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm	0.1 in	2.54 mm	2			6.1 mm	0.24 in
Sullins Connector Solutions PEC24SGBN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	8.08 mm	0.318 in	3 A	All	-65 ░C	125 °C	24	Right Angle Through Hole	0.14 in	3.56 mm			Square			1	0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm								5.08 mm	0.2 "
Sullins Connector Solutions PEC24DACN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	48	Through Hole	0.1 in	2.54 mm	8.13 mm	0.32 in	Square				0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm	0.1 in	2.54 mm	2	16.51 mm	0.65 in
Sullins Connector Solutions PEC24SAFN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	24	Through Hole	0.1 in	2.54 mm			Square			1	0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm				24.13 mm	0.95 in			15.75 mm	0.62 "
Sullins Connector Solutions PEC24SBDN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	24	Right Angle Through Hole	0.14 in	3.56 mm	10.16 mm	0.4 in	Square			1	0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm
Sullins Connector Solutions PEC24SACN	2.54 µm	100 µin	UL94 V-0	Header Breakaway	Polybutylene Terephthalate (PBT)	5.84 mm	0.23 in	3 A	All	-65 ░C	125 °C	24	Through Hole	0.1 in	2.54 mm	8.13 mm	0.32 in	Square			1	0.1 "	2.54 mm	Male Pin	Unshrouded	Phosphor Bronze	Push-Pull	Board to Board Cable	Solder	Tin	Black	100 çin	2.54 çm				16.51 mm	0.65 in
