ECQ-E2185 Series

Manufacturer: Panasonic Electronic Components

Catalog

ECQE(B), MET POLYESTER FILM CAP RADIAL L ROHS COMPLIANT: YES

Part	Mounting Type	Tolerance	Applications	Voltage Rating - DC	Capacitance	Termination	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Height - Seated (Max) [z]	Height - Seated (Max)
Panasonic Electronic Components ECQ-E2185JBB	Through Hole	5 %	General Purpose	250 V	1.8 µF	PC Pins	0.772 in	19.6 mm	0.394 in	10 mm	Polyester Metallized	-40 C	105 ░C	Radial
Panasonic Electronic Components ECQ-E2185JF	Through Hole	5 %	General Purpose	250 V	1.8 µF	PC Pins			0.886 in	22.5 mm	Polyester Metallized	-40 C	105 ░C	Radial	1.024 in	7.5 mm	26 mm	0.295 in	0.65 in	16.5 mm
Panasonic Electronic Components ECQ-E2185RKB	Through Hole	10 %	General Purpose	250 V	1.8 µF	PC Pins	0.772 in	19.6 mm	0.689 in	17.5 mm	Polyester Metallized	-40 C	105 ░C	Radial
Panasonic Electronic Components ECQ-E2185KS	Through Hole	10 %	General Purpose	250 V	1.8 µF	PC Pins			1.083 in	27.5 mm	Polyester Metallized	-40 C	85 °C	Radial	1.22 in		31 mm	0.335 in	0.748 in	19 mm	8.5 mm
Panasonic Electronic Components ECQ-E2185KFW	Through Hole	10 %	General Purpose	250 V	1.8 µF	PC Pins			0.591 in	15 mm	Polyester Metallized	-40 C	105 ░C	Radial	1.024 in	7.5 mm	26 mm	0.295 in	0.807 in			20.5 mm
Panasonic Electronic Components ECQ-E2185KFB	Through Hole	10 %	General Purpose	250 V	1.8 µF	PC Pins			0.591 in	15 mm	Polyester Metallized	-40 C	105 ░C	Radial	1.024 in	7.5 mm	26 mm	0.295 in	0.807 in			20.5 mm
Panasonic Electronic Components ECQ-E2185JB	Through Hole	5 %	General Purpose	250 V	1.8 µF	PC Pins	0.614 in		0.689 in	17.5 mm	Polyester Metallized	-40 C	105 ░C	Radial									15.6 mm
