SRP7030CA Series
Manufacturer: Bourns Inc.
Beta
⌘K
INDUCTOR POWER SHIELDED WIREWOUND 1UH 20% 100KHZ METAL ALLOY POWDER 21.8A 0.005OHM DCR AUTOMOTIVE AEC-Q200 T/R
| Part | Features | Mounting Type | Inductance Frequency - Test | Shielding | Frequency - Self Resonant | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Tolerance | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Ratings | Material - Core | Current Rating (Amps) | Inductance | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Current - Saturation (Isat) | DC Resistance (DCR) [Max] | DC Resistance (DCR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Flat Wire High Saturation | Surface Mount | 100 kHz | Shielded | 35 MHz | 0.299 " | 7.6 mm | 0.307 " | 7.8 mm | 20 % | Nonstandard | 155 C | -55 C | AEC-Q200 | Carbonyl Powder | 21.8 A | 1 µH | 0.122 in | 3.1 mm | 30 A | 5 mOhm | |
Bourns Inc. | Flat Wire High Saturation | Surface Mount | 100 kHz | Shielded | 18 MHz | 0.299 " | 7.6 mm | 0.307 " | 7.8 mm | 20 % | Nonstandard | 155 C | -55 C | AEC-Q200 | Carbonyl Powder | 9 A | 4.7 ÁH | 0.122 in | 3.1 mm | 13.5 A | 26.7 mOhm | |
 Bourns Inc. | Flat Wire High Saturation | Surface Mount | 100 kHz | Shielded | 0.299 " | 7.6 mm | 0.307 " | 7.8 mm | 20 % | Nonstandard | 155 C | -55 C | AEC-Q200 | Carbonyl Powder | 2.7 µH | 0.122 in | 3.1 mm | |||||
Bourns Inc. | Flat Wire High Saturation | Surface Mount | 100 kHz | Shielded | 38 MHz | 0.299 " | 7.6 mm | 0.307 " | 7.8 mm | 20 % | Nonstandard | 155 C | -55 C | AEC-Q200 | Carbonyl Powder | 13 A | 2.2 µH | 0.122 in | 3.1 mm | 19 A | 13.7 mOhm |
