MRF6 Series

Catalog

RF MOSFET LDMOS 50V NI780

Part	Package / Case	Gain	Frequency	Voltage - Rated	Current - Test	Mounting Type	Voltage - Test	Power - Output	Supplier Device Package	Frequency [Max]	Frequency [Min]
Freescale Semiconductor - NXP MRF6V14300HSR3	NI-780S	18 dBi	1.4 GHz	100 V	150 mA	Chassis Mount	50 V	330 W
Freescale Semiconductor - NXP MRF6S19120HR5	SOT-957A	15 dB	1.99 GHz	68 V	1 A		28 V	19 W	NI-780H-2L
Freescale Semiconductor - NXP MRF6S27085HR3	SOT-957A	15.5 dBi	2.66 GHz	68 V	900 mA		28 V	20 W	NI-780H-2L
Freescale Semiconductor - NXP MRF6V4300NBR5	TO-272BB	22 dBi	450 MHz	110 V	900 mA	Chassis Mount	50 V	300 W	TO-272 WB-4
Freescale Semiconductor - NXP MRF6V2010NR1	TO-270AA	23.9 dB	220 MHz	110 V	30 mA	Surface Mount	50 V	10 W	TO-270-2
Freescale Semiconductor - NXP MRF6S19140HR5	NI-880	16 dB		68 V	1.15 A		28 V	29 W	NI-880	1.99 GHz	1.93 GHz
Freescale Semiconductor - NXP MRF6V13250HR5	SOT-957A		1.3 GHz	120 VDC	100 mA		50 V	250 W	NI-780H-2L
Freescale Semiconductor - NXP MRF6P9220HR3	NI-860C3	20 dBi	880 MHz	68 V	1.6 A		28 V	47 W	NI-860C3
Freescale Semiconductor - NXP MRF6S21140HR3	SOT-957A	15.5 dBi		68 V	1.2 A	Chassis Mount	28 V	30 W	NI-880H-2L
Freescale Semiconductor - NXP MRF6S18100NBR1	TO-272BB	14.5 dBi	1.99 GHz	68 V	900 mA		28 V	100 W	TO-272 WB-4
