E3Z-R81 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
IO-L RETRO 4M COM2 PRE-W
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Response Time | Ingress Protection | Output Configuration | Connection Method | Light Source | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Method | Sensing Distance | Sensing Distance | Sensing Distance [Min] | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Max] | Sensing Distance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | |||||||||||||||||
 Omron Automation and Safety | |||||||||||||||||
 Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Connector | Red (660nm) | 12 VDC | 24 V | Retroreflective | 157.48 in | 4 m | |||||
 Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IEC IP67 IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Cable | Red (660nm) | 12 VDC | 24 V | Retroreflective | 3.937 " | 10 cm | 157.48 in | 4000 mm | ADJ | ||
 Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IEC IP67 IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Cable | Red (660nm) | 12 VDC | 24 V | Retroreflective | 3.937 " | 10 cm | 157.48 in | 4000 mm | ADJ | ||
Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IEC IP67 IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Connector | Red (660nm) | 12 VDC | 24 V | Retroreflective | 3.937 " | 10 cm | 157.48 in | 4000 mm | ADJ | ||
Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IEC IP67 IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Cable | Red (660nm) | 12 VDC | 24 V | Retroreflective | 118.11 in | 3 m | |||||
Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IEC IP67 IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Connector | Red (660nm) | 12 VDC | 24 V | Retroreflective | 3.937 " | 10 cm | 157.48 in | 4000 mm | ADJ | ||
Omron Automation and Safety | 55 °C | -25 °C | 1 ms | IEC IEC IP67 IP67 IP69K | PNP - Dark-ON/Light-ON - Selectable | Connector | Red (660nm) | 12 VDC | 24 V | Retroreflective | 118.11 in | 3 m | |||||
Omron Automation and Safety |
