MVR07 Series

Manufacturer: Meritek

Catalog

VARISTOR 270V 1200A 7MM DISC THR

Part	Current - Surge	Maximum AC Volts [Max]	Capacitance @ Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Maximum DC Volts [Max]	Varistor Voltage (Min) [Min]	Varistor Voltage (Max) [Max]	Package / Case	Number of Circuits	Varistor Voltage (Typ)	Energy	Varistor Voltage (Max)	Maximum DC Volts	Features
Meritek MVR07D271K	1200 A	175 V	1 kHz 185 pF	-40 C	105 ░C	Through Hole	225 V	243 V	297 V	Disc 7mm	1	270 V	18 J
Meritek MVR07D431K	1200 A	275 V	115 pF	-40 C	105 ░C	Through Hole	350 V	387 V		Disc 7mm	1	430 V	28 J	473 V
Meritek MVR07D470K	250 A	30 V	1100 pF	-40 C	105 ░C	Through Hole		42 V	52 V	Disc 7mm	1	47 V	2.5 J		38 V
Meritek MVR07D621K	1200 A	385 V	80 pF	-40 C	105 ░C	Through Hole	505 V	558 V		Disc 7mm	1	620 V	33 J
Meritek MVR07D390K	250 A	25 V	1 kHz 1300 pF	-40 C	105 ░C	Through Hole	31 V	35 V	43 V	Disc 7mm	1	39 V	2.1 J
Meritek MVR07D431K-S	1750 A	275 V	115 pF	-40 C	105 ░C	Through Hole	350 V	387 V		Disc 7mm	1	430 V	40 J	473 V		High Surge
Meritek MVR07D391K	1200 A	250 V	130 pF	-40 C	105 ░C	Through Hole	320 V	351 V	429 V	Disc 7mm	1	390 V	25 J
Meritek MVR07D471K	1200 A	300 V	105 pF	-40 C	105 ░C	Through Hole	385 V	423 V	517 V	Disc 7mm	1	470 V	30 J
Meritek MVR07D180K	250 A	11 V	1 kHz 2800 pF	-40 C	105 ░C	Through Hole	14 V	15 V	21.6 V	Disc 7mm	1	18 V	0.9 J
Meritek MVR07D241K	1200 A	150 V	210 pF	-40 C	105 ░C	Through Hole	200 V	216 V	264 V	Disc 7mm	1	240 V	15 J
