ASMT-JW32 Series
Manufacturer: Broadcom Limited
Beta
⌘K
LED COOL WHITE 7250K 1616
| Part | Thermal Resistance of Package | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Lumens/Watt @ Current - Test | Flux @ 25°C, Current - Test [Max] | Flux @ 25°C, Current - Test [Min] | Flux @ 25°C, Current - Test | Package / Case | Voltage - Forward (Vf) (Typ) | Viewing Angle | Current - Test | Current - Max [Max] | Mounting Type | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | CCT (K) [Min] | CCT (K) | CCT (K) [Max] | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Broadcom Limited | 9 °C/W | 0.157 " | 4 mm | 0.157 in | 4 mm | 125 lm/W | 168 lm | 114 lm | 140 lm | 1616 (4040 Metric) | 3.2 V | 140 ° | 350 mA | 700 mA | Surface Mount | 0.077 in | 1.95 mm | 4500 K | 7250 K | 10000 K | Cool White |
