TFA0412 Series
Manufacturer: Delta Electronics
Beta
⌘K
FAN AXIAL 40X28MM 12VDC WIRE
| Part | Current Rating (Amps) | Voltage Range [Min] | Voltage Range [Max] | Material - Blade | Material - Frame | Power (Watts) | Approval Agency | RPM | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Rated | Static Pressure | Static Pressure | Weight [custom] | Weight [custom] | Termination | Fan Type | Size / Dimension [x] | Size / Dimension [z] | Noise | Air Flow | Air Flow | Width [x] | Features | Bearing Type | Lifetime @ Temp. | Ingress Protection | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 0.42 A | 8 V | 13.2 VDC | Plastic | Plastic | 5.04 W | CE cURus TUV | 15600 RPM | 70 °C | -10 °C | 12 VDC | 402.8 Pa | 1.617 in H2O | 47.17 g | 0.104 lb | 4 Wire Leads | Tubeaxial | 40 mm | 40 mm | 50.8 dB(A) | 22.2 CFM | 0.622 m³/min | 28 mm | Locked Rotor Protection PWM Control Speed Sensor (Tach) | Ball | ||||
 Delta Electronics | 600 mA | 7 V | 13.2 VDC | Plastic | Plastic | 7.2 W | CE cURus TUV | 17600 RPM | 70 °C | -10 °C | 12 VDC | 465.3 Pa | 1.868 in H2O | 4 Wire Leads | Tubeaxial | 40 mm | 40 mm | 55 dB(A) | 25.3 CFM | 0.708 m³/min | 28 mm | Locked Rotor Protection PWM Control Speed Sensor (Tach) | Ball | 70000 Hrs | IP51 - Dust Protected | 44.45 g | 0.098 lb |
