807-019 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 38POS 0.156
| Part | Read Out | Gender | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Color | Pitch | Pitch | Termination Rows | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Finish | Contact Material | Termination | Contact Type | Number of Positions/Bay/Row | Mounting Type | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Dual | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | 2 | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Gold | Copper Alloy | Solder | Semi Bellows | 19 | Right Angle Through Hole | 38 | ||||
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | Non Specified - Single Edge | Tin | Copper Alloy | Wire Wrap | Semi Bellows | 19 | Through Hole | 19 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1 | |||
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | Non Specified - Single Edge | Tin | Copper Alloy | Wire Wrap | Semi Bellows | 19 | Through Hole | 19 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 1 | |||
 EDAC Inc. | Dual | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | 2 | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Gold | Copper Alloy | Solder | Semi Bellows | 19 | Right Angle Through Hole | 38 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | Non Specified - Single Edge | Tin | Copper Alloy | Wire Wrap | Semi Bellows | 19 | Through Hole | 19 | 4-40 Flush Mount Threaded Insert Top Opening | 1 | |||||
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Gold | Copper Alloy | Wire Wrap | Semi Bellows | 19 | Through Hole | 19 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1 | |
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | Non Specified - Single Edge | Tin | Copper Alloy | Solder | Semi Bellows | 19 | Through Hole | 19 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1 | |||
 EDAC Inc. | Dual | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | 2 | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Gold | Copper Alloy | Solder | Semi Bellows | 19 | Right Angle Through Hole | 38 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Gold | Copper Alloy | Solder | Semi Bellows | 19 | Through Hole | 19 | 1 | ||||
 EDAC Inc. | Single | Female | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Green | 3.96 mm | 0.156 in | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Gold | Copper Alloy | Solder | Semi Bellows | 19 | Through Hole | 19 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 1 |
