BGA Low Profile Series

Manufacturer: Advanced Thermal Solutions Inc.

Catalog

HEAT SINKS MAXIFLOW BGA HEAT SINK W/MAXIGRIP ATTACHMENT, T412, 40X40X19.5MM, 69.1MM FIN TIP

Part	Thermal Resistance @ Forced Air Flow	Material Finish	Material	Width [y]	Width [y]	Type	Attachment Method	Package Cooled	Shape [custom]	Shape [custom]	Fin Height	Fin Height	Width [x]	Width [x]	Length	Length	Width	Width	Length [x]	Length [x]	Fin Height [custom]	Fin Height [custom]
Advanced Thermal Solutions Inc. ATS-51400R-C1-R0	2 °C/W	Black Anodized	Aluminum	1.575 in	40 mm	Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	19.5 mm	0.768 in
Advanced Thermal Solutions Inc. ATS-51170D-C1-R0	18.5 °C/W	Blue Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	9.5 mm	0.374 in	0.669 in	17 mm	17 mm	0.669 in
Advanced Thermal Solutions Inc. ATS-51450R-C1-R0	1.6 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	19.5 mm	0.768 in					1.772 in	45 mm	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-51210R-C1-R0	5.3 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	19.5 mm	0.768 in	0.827 in	21 mm					0.827 in	21 mm
Advanced Thermal Solutions Inc. ATS-51450K-C1-R0	2.1 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square							1.772 in	45 mm	1.772 in	45 mm	0.571 in	14.5 mm
Advanced Thermal Solutions Inc. ATS-51310R-C1-R0	3.2 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	19.5 mm	0.768 in	1.22 in	30.99 mm					1.22 in	30.99 mm
Advanced Thermal Solutions Inc. ATS-51400K-C1-R0	2.5 °C/W	Black Anodized	Aluminum	1.575 in	40 mm	Top Mount	Clip Thermal Material	BGA	Angled Fins	Square											0.571 in	14.5 mm
Advanced Thermal Solutions Inc. ATS-51230R-C1-R0	5 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	19.5 mm	0.768 in	0.906 in	23.01 mm					0.9 in	23 mm
Advanced Thermal Solutions Inc. ATS-51270D-C1-R0	8 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	9.5 mm	0.374 in			27 mm	1.063 in	1.063 in	27 mm
Advanced Thermal Solutions Inc. ATS-51270R-C1-R0	3.6 °C/W	Black Anodized	Aluminum			Top Mount	Clip Thermal Material	BGA	Angled Fins	Square	19.5 mm	0.768 in			27 mm	1.063 in	1.063 in	27 mm
