628-8W8 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 8POS VERT SLDR
| Part | Contact Material | Voltage Rating | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Features | Termination | Shell Material, Finish | Contact Type | Connector Type | Mounting Type | Material Flammability Rating | Connector Style | Contact Finish | Shell Size, Connector Layout [x] | Shell Size, Connector Layout | Flange Feature | Current Rating (Amps) | Contact Finish Thickness | Flange Feature [custom] | Flange Feature [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 30 Áin | 0.76 Ám | 8 | Board Lock Shielded | Solder | Nickel Plated Steel | Coax Signal | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | Board Side (4-40) | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 8 | Shielded | Solder | Nickel Plated Steel | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | Board Side (M3) | 10 A | Flash | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 30 Áin | 0.76 Ám | 8 | Shielded | Nickel Plated Steel | Coax Signal | Receptacle Female Sockets | Free Hanging (In-Line) | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | Board Side (4-40) | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 8 | Shielded | Solder | Nickel Plated Steel | Coax Signal | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | Board Side (4-40) | Flash | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 8 | Shielded | Solder | Nickel Plated Steel | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | Board Side (4-40) | 40 A | Flash | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 8 | Board Lock Shielded | Solder | Nickel Plated Steel | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | M3 | 20 A | Flash | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 30 Áin | 0.76 Ám | 8 | Shielded | Solder | Nickel Plated Steel | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | 30 A | 4-40 | 4-40 | ||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 8 | Shielded | Solder | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | M3 | 20 A | Flash | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 8 | Shielded | Solder | Nickel Plated Steel | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | 20 A | Flash | 4-40 | 4-40 | |||
 EDAC Inc. | Copper Alloy | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Black | 1 | 30 Áin | 0.76 Ám | 8 | Board Lock Shielded | Solder | Nickel Plated Steel | Signal and Power | Receptacle Female Sockets | Through Hole | UL94 V-0 | Combo D-Sub | Gold | 4 | 8W8 C DC | 4-40 | 30 A |
