PRF20 Series

Manufacturer: CUI Inc.

Catalog

DC DC CONVERTER 15V 20W

Part	Number of Outputs	Voltage - Output 1	Standard Number	Mounting Type	Voltage - Input (Max) [Max]	Applications	Type	Size / Dimension	Features	Control Features	Current - Output (Max) [Max]	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Voltage - Input (Min) [Min]	Approval Agency	Power (Watts)	Efficiency	Current - Output (Max)	Current - Output (Max)	Voltage - Output 2
CUI Inc. PRF20-Q110-S15N	1	15 V	60950-1	Through Hole	160 V	ITE (Commercial)	Isolated Module	0.4 in 10.2 mm 25.4 mm 50.8 mm	OCP OVP Remote On/Off SCP UVLO	Active Low Enable	1.33 A	6-DIP Module	85 °C	-40 C	2250 VDC	43 V	UL	20 W
CUI Inc. PRF20-Q110-D12	2	12 V	60950-1	Through Hole	160 V	ITE (Commercial)	Isolated Module	0.4 in 10.2 mm 25.4 mm 50.8 mm	OCP OVP Remote On/Off SCP UVLO	Active High Enable		6-DIP Module	85 °C	-40 C	2250 VDC	43 V	UL	20 W	89 %	833 mA	833 mA	-12 V
CUI Inc. PRF20-Q110-D12N	2	12 V	60950-1	Through Hole	160 V	ITE (Commercial)	Isolated Module	0.4 in 10.2 mm 25.4 mm 50.8 mm	OCP OVP Remote On/Off SCP UVLO	Active Low Enable		6-DIP Module	85 °C	-40 C	2250 VDC	43 V	UL	20 W	89 %	833 mA	833 mA	-12 V
CUI Inc. PRF20-Q110-S15	1	15 V	60950-1	Through Hole	160 V	ITE (Commercial)	Isolated Module	0.4 in 10.2 mm 25.4 mm 50.8 mm	OCP OVP Remote On/Off SCP UVLO	Active High Enable	1.33 A	6-DIP Module	85 °C	-40 C	2250 VDC	43 V	UL	20 W
CUI Inc. PRF20-Q110-S12N	1	12 V	60950-1	Through Hole	160 V	ITE (Commercial)	Isolated Module	0.4 in 10.2 mm 25.4 mm 50.8 mm	OCP OVP Remote On/Off SCP UVLO	Active Low Enable	1.67 A	6-DIP Module	85 °C	-40 C	2250 VDC	43 V	UL	20 W	90 %
