M18-3V Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
M18-3 SERIES: NICKEL-PLATED BRASS: DIFFUSE REFLECTIVE
| Part | Ingress Protection | Adjustment Type | Sensing Method | Connection Method | Operating Temperature [Max] | Operating Temperature [Min] | Sensing Distance | Sensing Distance | Output Configuration | Voltage - Supply [Min] | Voltage - Supply [Max] | Light Source | Cable Length | Cable Length | Response Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Diffuse | Cable with Connector | 70 °C | -40 C | 750 mm | 29.528 " | NPN | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms |
 BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Cable with Connector | 70 °C | -40 C | 5 cm | 1.969 in | PNP | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms | |
BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Cable with Connector | 70 °C | -40 C | 75 mm | 2.953 in | PNP | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms | |
 BANNER ENGINEERING | IP67 IP69K | Adjustable Potentiometer | Diffuse | Connector | 70 °C | -40 C | 750 mm | 29.528 " | PNP - Dark-ON/Light-ON | 10 VDC | 30 VDC | Red LED | 1.5 ms | ||
BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Cable with Connector | 70 °C | -40 C | 30 mm | 1.181 in | PNP | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms | |
BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Cable with Connector | 70 °C | -40 C | 15 cm | 5.906 " | PNP | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms | |
BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Retroreflective | Cable with Connector | 70 °C | -40 C | 7.5 m | 24.61 ft | PNP | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms |
BANNER ENGINEERING | IEC 60529 IP67 IP69K | 250° Turn Potentiometer Adjustable | Diffuse | Cable with Connector | 70 °C | -40 C | 30 cm | 11.811 " | NPN | 10 VDC | 30 VDC | Red LED | 78.74 " | 2 m | 1.5 ms |
