9458MN Series

Catalog

CABLE 15COND 20AWG YELLOW

Part	Length	Length	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Jacket (Insulation) Material	Features	Number of Conductors	Conductor Strand [custom]	Conductor Strand [custom]	Usage	Cable Type	Jacket Color	Conductor Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature [Max]	Operating Temperature [Min]	Wire Gauge	Conductor Insulation	Voltage	Length [x]	Length [x]
Belden Inc. 9458MN 0041000	304.8 m	1000 ft	7.62 mm	0.3 in	UL Style 2937	Poly-Vinyl Chloride (PVC)	Drain Wire	15	26	34 AWG	Audio Control Instrumentation	Multi-Conductor	Yellow	Copper Tinned	0.406 mm	0.016 in	80 °C	-20 ░C	20 AWG	Polypropylene (PP)	300 VDC
Belden Inc. 9458MN 004100			7.62 mm	0.3 in	UL Style 2937	Poly-Vinyl Chloride (PVC)	Drain Wire	15	26	34 AWG	Audio Control Instrumentation	Multi-Conductor	Yellow	Copper Tinned	0.406 mm	0.016 in	80 °C	-20 ░C	20 AWG	Polypropylene (PP)	300 VDC	100 ft	30.5 m
Belden Inc. 9458MN 008100			7.62 mm	0.3 in	UL Style 2937	Poly-Vinyl Chloride (PVC)	Drain Wire	15	26	34 AWG	Audio Control Instrumentation	Multi-Conductor	Gray	Copper Tinned	0.406 mm	0.016 in	80 °C	-20 ░C	20 AWG	Polypropylene (PP)	300 VDC	100 ft	30.5 m
