430105 Series
Manufacturer: Curtis Industries
Beta
⌘K
CONN BARRIER STRP 17CIRC 0.438"
| Part | Material - Insulation | Mounting Type | Operating Temperature | Material Flammability Rating | Number of Circuits | Current Rating (Amps) | Features | Number of Rows | Pitch [x] | Pitch [x] | Terminal Block Type | Voltage Rating | Barrier Type | Number of Wire Entries | Wire Gauge [Max] | Wire Gauge [Min] | Bottom Termination | Top Termination | Number of Circuits [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 17 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 17 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 19 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 19 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
 Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 1 | 20 A | Flange | 1 | Barrier Block | 600 V | 2 Wall (Dual) | 1 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |||
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 18 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 18 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 2 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 2 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 12 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 12 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 22 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 22 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 15 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 15 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 26 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 26 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | |
Curtis Industries | Polypropylene (PP) | Chassis Panel Through Hole | 105 C | UL94 V-0 | 20 A | Flange | 1 | 0.438 in | 11.12 mm | Barrier Block | 600 V | 2 Wall (Dual) | 9 | 22 AWG | 12 AWG | PC Pin | Screws (Not Included) | 9 |
