1003P1 Series
Manufacturer: E-Switch
Catalog
SWITCH TOGGLE 3PDT 5A 120V
| Part | Actuator Material | Electrical Life | Voltage Rating - DC | Actuator Length [x] | Switch Function | Circuit | Actuator Type | Bushing Thread | Mounting Type | Features | Voltage Rating - AC | Panel Cutout Dimensions [diameter] | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Illumination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | Brass Chrome Plated | 28 V | 13 mm | On-On | 3PDT | Standard Round | 15/32-32 | Panel Mount | Epoxy Sealed Terminals | 120 V | 11.91 mm | 5 A | 85 °C | -30 ░C | PC Pin | Non-Illuminated | |
E-Switch | Brass Chrome Plated | 28 V | 5.08 mm | On-On | 3PDT | Standard Round | Unthreaded | Right Angle Through Hole | Epoxy Sealed Terminals | 120 V | 5 A | 85 °C | -30 ░C | PC Pin | Non-Illuminated | ||
E-Switch | Brass Chrome Plated | 20 V | 10.41 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount Right Angle Vertical | Epoxy Sealed Terminals | 20 V | 0.25 in | 0.4 VA | 85 °C | -30 ░C | PC Pin | Non-Illuminated | |
E-Switch | Brass Chrome Plated | 28 V | 10.41 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount | Epoxy Sealed Terminals | 120 V | 0.25 in | 5 A | 85 °C | -30 ░C | Wire Wrap | Non-Illuminated | |
E-Switch | Brass Chrome Plated | 20 V | 5.08 mm | On-On | 3PDT | Standard Round | Unthreaded | Through Hole | Epoxy Sealed Terminals | 20 V | 0.4 VA | 85 °C | -30 ░C | PC Pin | Non-Illuminated | ||
E-Switch | Brass Chrome Plated | 28 V | 10.41 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount Right Angle Vertical | Epoxy Sealed Terminals | 120 V | 0.25 in | 5 A | 85 °C | -30 ░C | PC Pin | Non-Illuminated | |
 E-Switch | Brass Chrome Plated | 28 V | 10.41 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount | Epoxy Sealed Terminals | 120 V | 0.25 in | 5 A | 85 °C | -30 ░C | PC Pin | Non-Illuminated | |
E-Switch | Brass Chrome Plated | 28 V | 21.34 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount | Epoxy Sealed Terminals | 120 V | 0.25 in | 5 A | 85 °C | -30 ░C | PC Pin | Non-Illuminated | |
E-Switch | Brass Chrome Plated | 28 V | 10.41 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount | Epoxy Sealed Terminals | 120 V | 0.25 in | 5 A | 85 °C | -30 ░C | Quick Connect - 0.062" (1.5mm) | Non-Illuminated | |
 E-Switch | Brass Chrome Plated | 28 V | 5.08 mm | On-On | 3PDT | Standard Round | 1/4-40 | Panel Mount | Epoxy Sealed Terminals | 120 V | 0.25 in | 5 A | 85 °C | -30 ░C | PC Pin | Non-Illuminated |
