Q20P Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTOELECTRIC SENSORS WORLD-BEAM Q20 SERIES: RETRO; RANGE: 6 M; INPUT 10-30 V DC; OUTPUT: COMPLEMENTARY SOLID-STATE PNP; 150 MM (6 IN) M8 PIGTAIL QD
| Part | Ingress Protection | Light Source | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Distance | Sensing Distance | Response Time | Output Configuration | Connection Method | Sensing Method | Adjustment Type | Operating Temperature [Min] | Operating Temperature [Max] | Light Source | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Red (645nm) | 10 VDC | 30 VDC | 236.22 " | 6 m | 800 µs | PNP - Dark-ON/Light-ON - Selectable | Connector | Retroreflective NonPolarized | Adjustable Potentiometer | -20 ░C | 60 °C | |||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Red (655nm) | 10 VDC | 30 VDC | 3.937 in | 10 cm | 800 µs | PNP - Dark-ON/Light-ON | Connector | Background Suppression | -20 ░C | 60 °C | ||||
 BANNER ENGINEERING | IP67 NEMA 6P | Red LED | 10 VDC | 30 VDC | 7.874 in | 200 mm | 2.8 ms | PNP - Dark-ON/Light-ON | Connector | Background Suppression | Adjustable Potentiometer | -20 ░C | 60 °C | |||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Infrared | 10 VDC | 30 VDC | 4.9 ft | 1.5 m | 800 µs | PNP - Dark-ON/Light-ON | Connector | Diffuse | Adjustable Potentiometer | -20 ░C | 60 °C | 850 nm | ||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Infrared | 10 VDC | 30 VDC | 4.9 ft | 1.5 m | 800 µs | PNP - Dark-ON/Light-ON - Selectable | Connector | Diffuse | Adjustable Potentiometer | -20 ░C | 60 °C | 850 nm | ||
BANNER ENGINEERING | IP67 NEMA 6P | Red LED | 10 VDC | 30 VDC | 7.874 in | 200 mm | 2.8 ms | PNP - Dark-ON/Light-ON | Connector | Background Suppression | Adjustable Potentiometer | -20 ░C | 60 °C | |||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Red (624nm) | 10 VDC | 30 VDC | 472.441 " | 12 m | 1 ms | PNP - Dark-ON/Light-ON | Cable | Through-Beam | -20 ░C | 60 °C | 78.74 " | 2 m | ||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Red (645nm) | 10 VDC | 30 VDC | 13.12 ' | 4 m | 800 µs | PNP - Dark-ON/Light-ON | Cable | Polarized Retroreflective | Adjustable Potentiometer | -20 ░C | 60 °C | 78.74 " | 2 m | |
BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Infrared | 10 VDC | 30 VDC | 4.9 ft | 1.5 m | 800 µs | PNP - Dark-ON/Light-ON | Cable | Diffuse | Adjustable Potentiometer | -20 ░C | 60 °C | 850 nm | 78.74 " | 2 m |
 BANNER ENGINEERING | IEC IP67 NEMA 6P | Infrared | 10 VDC | 30 VDC | 787.402 in | 2000 cm | 1 ms | PNP - Dark-ON/Light-ON - Selectable | Connector | Through-Beam | -20 ░C | 60 °C | 850 nm |
