219XA

219XA Series

FUS 5X20 PGT T EBC 2.5A/250V HIGH I2T-P

Manufacturer: LITTELFUSE

Catalog

FUS 5X20 PGT T EBC 2.5A/250V HIGH I2T-P

Description

AI

5x20mm time-Lag glass body cartridge fuse designed to IEC specification

Catalog

FUS 5X20 PGT T EBC 2.5A/250V HIGH I2T-P

Part	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [diameter]	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Fuse Type	Response Time	Approval Agency	Melting I²t	Package / Case [x]	Package / Case [y]	Current Rating (Amps)	Voltage Rating - AC	Breaking Capacity @ Rated Voltage	DC Cold Resistance
LITTELFUSE 0219004.TXAP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA PSE SEMKO UL VDE	330 I²t	5 mm	20 mm	4 A	250 V	150 A
LITTELFUSE 0219.630TXAP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA SEMKO UL VDE	4.82	5 mm	20 mm	0.63 A	250 V	150 A	0.275 Ohms
LITTELFUSE 021902.5MXABP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA PSE SEMKO UL VDE	138	5 mm	20 mm	2.5 A	250 V	150 A
LITTELFUSE 0219.315MXABP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA SEMKO UL VDE	1.23	5 mm	20 mm	0.315 A	250 V	150 A
LITTELFUSE 0219.040MXAP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CE SEMKO UL	0.011	5 mm	20 mm	40 mA	250 V	150 A
LITTELFUSE 0219.200MXABP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA SEMKO UL VDE	0.32 I²t	5 mm	20 mm	0.2 A	250 V	150 A	1.6 Ohms
LITTELFUSE 0219.250MXAP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA SEMKO UL VDE	0.54 I²t	5 mm	20 mm	0.25 A	250 V	150 A
LITTELFUSE 0219.500MXAP	20 mm	0.205 in	0.787 "	5.2 mm	Requires Holder	-55 C	125 °C	Cartridge Glass	Slow Blow	CCC CE CSA SEMKO UL VDE	3	5 mm	20 mm	0.5 A	250 V	150 A
