628-43W Series
Manufacturer: EDAC Inc.
Beta
⌘K
COMBINATION LAYOUT D SUB CONNECTOR, 628C SERIES, DD-43W2, RECEPTACLE, 43 CONTACTS
| Part | Voltage Rating | Dielectric Material | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Connector Type | Features | Contact Type | Material Flammability Rating | Termination | Contact Finish | Flange Feature | Number of Positions [custom] | Number of Positions [custom] | Number of Rows [custom] | Mounting Type | Connector Style | Shell Material, Finish | Shell Size, Connector Layout | Shell Size, Connector Layout | Number of Positions | Current Rating (Amps) | Contact Finish Thickness | Current Rating (Amps) | Flange Feature [custom] | Flange Feature [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Shielded | Coax Signal | UL94 V-0 | Solder | Gold | Board Side (4-40) | 2 | 41 | 3 | Through Hole | Combo D-Sub | Nickel Plated Steel | 43W2 D DD | 5 | ||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Shielded | Signal and Power | UL94 V-0 | Solder | Gold | Housing/Shell (Unthreaded) | 3 | Through Hole | Combo D-Sub | Nickel Plated Steel | 43W2 D DD | 5 | 43 | 10A 5A | ||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Shielded | Signal and Power | UL94 V-0 | Solder | Gold | Board Side (4-40) | 3 | Through Hole | Combo D-Sub | Nickel Plated Steel | 43W2 D DD | 5 | 43 | 20A 5A | ||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Board Lock Shielded | Signal and Power | UL94 V-0 | Solder | Gold | Board Side (4-40) | 3 | Through Hole | Combo D-Sub | 43W2 D DD | 5 | 43 | 10A 5A | |||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Shielded | Coax Signal | UL94 V-0 | Gold | Board Side (4-40) | 2 | 41 | 3 | Free Hanging (In-Line) | Combo D-Sub | 43W2 D DD | 5 | ||||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | Receptacle Female Sockets | Shielded | Signal and Power | UL94 V-0 | Solder | Gold | Housing/Shell (Unthreaded) | 3 | Through Hole | Combo D-Sub | Nickel Plated Steel | 43W2 D DD | 5 | 43 | 20A 5A | Flash | |||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | Receptacle Female Sockets | Shielded | Signal and Power | UL94 V-0 | Gold | Housing/Shell (Unthreaded) | 3 | Free Hanging (In-Line) | Combo D-Sub | 43W2 D DD | 5 | 43 | Flash | 5 A 30 A | |||||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | Receptacle Female Sockets | Board Lock Shielded | Signal and Power | UL94 V-0 | Solder | Gold | 4-40 | 3 | Through Hole | Combo D-Sub | Nickel Plated Steel | 43W2 D DD | 5 | 43 | 20A 5A | Flash | |||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Shielded | Signal and Power | UL94 V-0 | Solder | Gold | 3 | Through Hole | Combo D-Sub | 43W2 D DD | 5 | 43 | 5 A 40 A | 4-40 | 4-40 | ||||||
 EDAC Inc. | 125 VDC | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 30 Áin | 0.76 Ám | Receptacle Female Sockets | Shielded | Coax Signal | UL94 V-0 | Solder | Gold | 2 | 41 | 3 | Through Hole | Combo D-Sub | Nickel Plated Steel | 43W2 D DD | 5 | 4-40 | 4-40 |
