RFSSMA Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
RF / COAXIAL CONNECTOR, SSMA COAXIAL, STRAIGHT FLANGED JACK, SOLDER, 50 OHM, BERYLLIUM COPPER
| Part | Mating Cycles | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Body Material | Shield Termination | Fastening Type | Connector Type | Mounting Feature | Connector Style | Number of Ports | Impedance | Center Contact Material | Housing Color | Mounting Type | Frequency - Max [Max] | Contact Termination | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | 500 | 350 VDC | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
 BULGIN LIMITED | 500 | 335 V | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
 BULGIN LIMITED | 500 | 350 VDC | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
 BULGIN LIMITED | 500 | 335 V | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Solder | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount Through Hole | 40 GHz | Solder | Extended Insulation |
 BULGIN LIMITED | 500 | 335 V | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
 BULGIN LIMITED | 500 | 335 V | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
BULGIN LIMITED | 500 | 350 VDC | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
 BULGIN LIMITED | 500 | 350 VDC | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
BULGIN LIMITED | 500 | 335 V | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression | |
BULGIN LIMITED | 500 | 350 VDC | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Stainless Steel | Screw | Threaded | Female Socket Jack | Flange | SSMA | 1 | 50 Ohms | Beryllium Copper | Silver | Panel Mount | 40 GHz | Compression |
