88859 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN FFC RCPT HSG 6POS 2.54MM
| Part | Note | Current Rating (Amps) | Housing Color | Material Flammability Rating | Locking Feature | Number of Positions | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Flat Flex Type | Number of Rows | Connector Type | Housing Material | FFC, FCB Thickness [Max] | FFC, FCB Thickness [Min] | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 6 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 8 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 7 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 13 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 15 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 10 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC | |
 TE Connectivity AMP Connectors | Contacts Not Included | 1.5 A | Black | UL94 V-0 | Detent Lock | 14 | 0.1 " | 2.54 mm | 105 ░C | -65 ░C | FFC | 1 | Housing for Female Contacts | Polybutylene Terephthalate (PBT) Glass Filled | 0.13 mm | 0.05 mm | 300 VDC |
