EEH-AZA Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
CAP ALUM HYBRID 47UF 20% 50V TH
| Part | ESR (Equivalent Series Resistance) | Applications | Ratings | Lead Spacing | Lead Spacing | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Size / Dimension [diameter] | Size / Dimension [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Capacitance | Ripple Current @ High Frequency | Type | Ripple Current @ Low Frequency | Lifetime @ Temp. | Package / Case | Mounting Type | Voltage - Rated | Tolerance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | 30 mOhms | Automotive | AEC-Q200 | 3.5 mm | 0.138 in | 0.413 in | 10.5 mm | 0.315 " | 8 mm | 105 ░C | -55 °C | 47 µF | 1.8 A | Hybrid | 270 mA | 10000 Hrs | Radial Can | Through Hole | 50 VDC | 20 % |
