2042 Series

Manufacturer: Oupiin

Catalog

PCB SOCKET, DOUBLE ROW, 22 PIN,

Part	Contact Finish Thickness - Post	Contact Shape	Insulation Material	Contact Material	Mounting Type	Number of Positions Loaded	Material Flammability Rating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Rows [custom]	Insulation Height	Insulation Height	Contact Type	Fastening Type	Connector Type	Contact Finish Thickness - Mating	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height [z]	Insulation Height [z]	Contact Finish - Post	Contact Finish - Mating	Number of Positions	Current Rating (Amps)	Pitch - Mating	Pitch - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Number of Rows
Oupiin 2042-2X11G00SA	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Through Hole	All	UL94 V-0	0.1 in	2.54 mm	2	0.224 in	5.7 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C	5.69 mm	0.224 in	Gold	Gold	22	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm
Oupiin 2042-1X05G00RB	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Right Angle Through Hole	All	UL94 V-0				0.098 "	2.5 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C			Gold	Gold	5	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm	1
Oupiin 2042-1X15G00SA	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Through Hole	All	UL94 V-0				0.224 in	5.7 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C	5.69 mm	0.224 in	Gold	Gold	15	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm	1
Oupiin 2042-1X04G00SB	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Through Hole	All	UL94 V-0				0.224 in	5.7 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C	5.69 mm	0.224 in	Gold	Gold	4	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm	1
Oupiin 2042-2X08G00RA	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Right Angle Through Hole	All	UL94 V-0	0.1 in	2.54 mm	2	0.197 "	5 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C			Gold	Gold	16	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm
Oupiin 2042-1X04G00RB	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Right Angle Through Hole	All	UL94 V-0				0.098 "	2.5 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C			Gold	Gold	4	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm	1
Oupiin 2042-1X10G00SA	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Through Hole	All	UL94 V-0				0.224 in	5.7 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C	5.69 mm	0.224 in	Gold	Gold	10	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm	1
Oupiin 2042-2X12G00SA	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Through Hole	All	UL94 V-0	0.1 in	2.54 mm	2	0.224 in	5.7 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C	5.69 mm	0.224 in	Gold	Gold	24	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm
Oupiin 2042-2X07G00SA	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Through Hole	All	UL94 V-0	0.1 in	2.54 mm	2	0.224 in	5.7 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C	5.69 mm	0.224 in	Gold	Gold	14	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm
Oupiin 2042-2X06G00RB	Flash	Square	Glass Filled Polyester Thermoplastic	Copper Alloy	Right Angle Through Hole	All	UL94 V-0	0.1 in	2.54 mm	2	0.197 "	5 mm	Female Socket	Push-Pull	Socket	Flash	Solder	-55 C	105 ░C			Gold	Gold	12	2 A	0.1 "	2.54 mm	0.126 "	3.2 mm
