887-039 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 39POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Pitch | Pitch | Card Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Number of Positions/Bay/Row | Termination | Contact Finish | Number of Positions | Color | Gender | Number of Rows | Read Out |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Copper Alloy | 39 | Solder | Gold | 39 | Black | Female | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 39 | Solder Eyelet(s) | Gold | 39 | Black | Female | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | 39 | Solder | Gold | 39 | Black | Female | 1 | Single | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 39 | Solder | Gold | 39 | Black | Female | 1 | Single | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | 39 | Wire Wrap | Gold | 39 | Black | Female | 1 | Single | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 39 | Solder Eyelet(s) | Gold | 39 | Black | Female | 1 | Single |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 39 | Wire Wrap | Gold | 39 | Black | Female | 1 | Single | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 39 | Solder | Gold | 39 | Black | Female | 1 | Single | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Copper Alloy | 39 | Solder | Gold | 39 | Black | Female | 1 | Single | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 125 °C | -40 C | Through Hole | 3.96 mm | 0.156 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 39 | Solder | Gold | 39 | Black | Female | 1 | Single |
