M2022TJ Series

Catalog

SWITCH ROCKER DPDT 6A 125V

Part	Mechanical Life	Electrical Life	Voltage Rating - DC	Voltage Rating - AC	Actuator Type	Current Rating (Amps)	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Operating Temperature [Max]	Operating Temperature [Min]	Switch Function	Color - Actuator/Cap	Actuator Marking	Termination Style	Mounting Type	Approval Agency	Features	Circuit	Illumination Type, Color	Illumination Voltage (Nominal)
NKK Switches M2022TJW01-FB-1A	50000 Cycles	25000 Steps	30 V	125 V	Concave	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	White	No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT
NKK Switches M2022TJW01-GC	50000 Cycles	25000 Steps	30 V	125 V	Paddle	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	Red	No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT
NKK Switches M2022TJW01-GH	50000 Cycles	25000 Steps	30 V	125 V	Paddle	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On		No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT
NKK Switches M2022TJW03-FC-2A-C	50000 Cycles	25000 Steps	30 V	125 V	Concave (Standard V) - Illuminated	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	Red	No Marking	PC Pin	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT	LED Red	2.8 VDC
NKK Switches M2022TJW01-GC-2A-C	50000 Cycles	25000 Steps	30 V	125 V	Paddle - Illuminated	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	Red	No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT	LED Red	2.8 VDC
NKK Switches M2022TJW01-FC-1C	50000 Cycles	25000 Steps	30 V	125 V	Concave	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	Red	No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT
NKK Switches M2022TJW01-GA-2A-C	50000 Cycles	25000 Steps	30 V	125 V	Paddle - Illuminated	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	Black	No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT	LED Red	2.8 VDC
NKK Switches M2022TJW02-FC-1A	50000 Cycles	25000 Steps	30 V	125 V	Concave	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On	Red	No Marking	Quick Connect - 0.062" (1.5mm)	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT
NKK Switches M2022TJW01-FC-3A-CF	50000 Cycles	25000 Steps	30 V	125 V	Concave (Standard V) - Illuminated	4 A 6 A	18.7 mm	15.9 mm	85 °C	-30 ░C	On-On	Red	No Marking	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT	Green/Red LED	2 VDC 2.25 VDC
NKK Switches M2022TJW01	50000 Cycles	25000 Steps	30 V	125 V	Actuator Arm Cap Required	4 A 6 A	15.9 mm	13.1 mm	85 °C	-30 ░C	On-On		Varies by Cap	Solder Lug	Panel Mount Snap-In	CSA UL	Epoxy Sealed Terminals	DPDT
