CABLE 196 Series
Manufacturer: GCT
Beta
⌘K
CBL ASSY SMA-MMCX JCK-PLG 5.906"
| Part | Length | Length | Ingress Protection | 1st Connector | 1st Contact Gender | Color | 1st Connector Mounting Feature | 2nd Contact Gender | 1st Connector Mounting Type | Style | Operating Temperature [Max] | Operating Temperature [Min] | Cable Impedance | Cable Type | 2nd Connector Mounting Type | 2nd Connector | Features | Overall Impedance | Frequency - Max [Max] | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
150 mm | 5.906 in | IP67/IP68 | SMA Jack | Female | Brown | Bulkhead - Front Side Nut | Male | Panel Mount | SMA to MMCX | 125 °C | -40 C | 50 Ohms | RG-178 | Free Hanging (In-Line) | MMCX Plug Right Angle | IP Rated Unmated | 50 Ohms | 3 GHz | |||
150 mm | 5.906 in | IP67/IP68 | SMA Jack | Female | Brown | Bulkhead - Front Side Nut | Male | Panel Mount | SMA to MMCX | 125 °C | -40 C | 50 Ohms | RG-178 | Free Hanging (In-Line) | MMCX Plug Right Angle | IP Rated Unmated | 50 Ohms | 3 GHz | |||
IP67/IP68 | SMA Jack | Female | Brown | Bulkhead - Front Side Nut | Male | Panel Mount | SMA to MMCX | 125 °C | -40 C | 50 Ohms | RG-178 | Free Hanging (In-Line) | MMCX Plug Right Angle | IP Rated Unmated | 50 Ohms | 3 GHz | 50 mm | 1.969 in | |||
IP67/IP68 | SMA Jack | Female | Brown | Bulkhead - Front Side Nut | Male | Panel Mount | SMA to MMCX | 125 °C | -40 C | 50 Ohms | RG-178 | Free Hanging (In-Line) | MMCX Plug Right Angle | IP Rated Unmated | 50 Ohms | 3 GHz | 50 mm | 1.969 in |
