LCBS-5 Series

Catalog

CBS LOCKING NYLON 3/4"

Part	Mounting Type	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Material	Support Hole Diameter [diameter]	Support Hole Diameter [diameter]	Features	Support Panel Thickness [custom]	Support Panel Thickness [custom]	Mounting Panel Thickness [Min]	Mounting Panel Thickness [Min]	Mounting Panel Thickness [Max]	Mounting Panel Thickness [Max]	Holding Type	Between Board Height	Between Board Height	Between Board Height	Support Panel Thickness	Support Panel Thickness	Support Panel Thickness	Length - Overall [x]	Length - Overall [x]	Mounting Hole Diameter [diameter]	Between Board Height
Essentra Components LCBS-5-12-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	19.05 mm	0.75 "	0.75 "
Essentra Components LCBS-5-01	Snap Lock	0.187 in	4.75 mm	Nylon	3.99 mm	0.157 "	Winged			0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	7.95 mm	0.3125 in	0.313 in	1.57 mm	0.062 in	0.0625 in	1.043 in	26.5 mm	0.1875 in
Essentra Components LCBS-5-5-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	7.95 mm	0.3125 in	0.313 in
Essentra Components LCBS-5-7-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	11.13 mm	0.4375 "	0.438 in
Essentra Components LCBS-5-HT	Snap Lock	0.187 in	4.75 mm	Nylon	3.99 mm	0.157 "	High Temperature Winged			1.4 mm	0.055 in	0.08 in	2.03 mm	Snap Lock	7.95 mm	0.3125 in	0.313 in	1.57 mm	0.062 in	0.0625 in	1.039 in	26.4 mm	0.1875 in
Essentra Components LCBS-5-19	Snap Lock	0.187 in	4.75 mm	Nylon	3.99 mm	0.157 "	Winged			0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	7.95 mm	0.3125 in	0.313 in	1.57 mm	0.062 in	0.0625 in	1.043 in	26.5 mm	0.1875 in
Essentra Components LCBS-5-20-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	31.75 mm		1.25 in
Essentra Components LCBS-5-18-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	28.58 mm		1.125 in
Essentra Components LCBS-5-22-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock		34.93 mm	1.375 in							1 3/8
Essentra Components LCBS-5-4-01	Snap Lock	0.189 "	4.8 mm	Nylon	3.99 mm	0.157 "	Winged	1.6 mm	0.063 in	0.79 mm	0.031 in	0.078 "	1.98 mm	Snap Lock	0.25 in		6.35 mm
