D-602 Series

Catalog

CONN SOCKET GALVANIZED SOLDER

Part	Contact Material	Pin or Socket	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Contact Termination	Type	Wire Gauge	Wire Gauge [Min]	Wire Gauge [Max]
TE Connectivity Aerospace, Defense and Marine D-602-0145	Beryllium Copper	Socket	Galvanized	50 µin	1.27 µm	Solder
TE Connectivity Aerospace, Defense and Marine D-602-44CS1024	Beryllium Copper	Pin	Gold			Solder
TE Connectivity Aerospace, Defense and Marine D-602-0185
TE Connectivity Aerospace, Defense and Marine D-602-45CS440	Copper Alloy	Assembly Coax Pin Center	Gold			Solder	Coaxial	179 316 RG-178
TE Connectivity Aerospace, Defense and Marine D-602-0127CS2853
TE Connectivity Aerospace, Defense and Marine D-602-0141	Beryllium Copper	Socket	Gold	50 µin	1.27 µm	Solder
TE Connectivity Aerospace, Defense and Marine D-602-45CS2820	Copper Alloy	Socket	Gold			Solder
TE Connectivity Aerospace, Defense and Marine D-602-0142	Beryllium Copper	Assembly Coax Socket Center	Gold	50 µin	1.27 µm	Solder	Coaxial		26 AWG	30 AWG
TE Connectivity Aerospace, Defense and Marine D-602-0147	Beryllium Copper	Socket	Gold	50 µin	1.27 µm	Solder			22 AWG	26 AWG
TE Connectivity Aerospace, Defense and Marine D-602-0171CS2831
