8408 Series
Manufacturer: Belden Inc.
Beta
⌘K
2 #16 EPDM BRD CSM
| Part | Shield Material | Shield Coverage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Number of Conductors | Jacket Color | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Material | Voltage | Cable Type | Wire Gauge | Usage | Conductor Insulation | Shield Type | Jacket (Insulation) Material | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Tinned Viscose | 85 % | 1.016 mm | 0.04 in | -30 ░C | 60 °C | 2 | Brown | 65 | 34 AWG | 9.65 mm | 0.38 " | Copper Tinned | 600 V | Microphone | 16 AWG | Audio | Ethylene Propylene Terpolymer Rubber (EPDM) | Double Braid | Chlorosulfonated Polyethylene (CSPE) | 152.4 m | 500 ft |
