1286AS Series

Catalog

INDUCTOR POWER SHIELDED WIREWOUND 1.5UH 20% 1MHZ METAL 1.8A 0.114OHM DCR 0806 T/R

Part	Type	Mounting Type	Inductance	Supplier Device Package	DC Resistance (DCR) [Max]	Shielding	Inductance Frequency - Test	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Tolerance	Material - Core	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	DC Resistance (DCR)
Murata Electronics 1286AS-H-1R5M=P2	Drum Core Wirewound	Surface Mount	1.5 µH	0806 (2016 Metric)	114 mOhm	Shielded	1 MHz	1.6 mm	0.079 in	0.063 "	2 mm	0806 (2016 Metric)	20 %	Iron Powder	2 A	85 °C	-40 C	1.2 mm	0.047 "
Murata Electronics 1286AS-H-1R0M=P2	Drum Core Wirewound	Surface Mount	1 µH	0806 (2016 Metric)		Shielded	1 MHz	1.6 mm	0.079 in	0.063 "	2 mm	0806 (2016 Metric)	20 %	Iron Powder	2.5 A	85 °C	-40 C	1.2 mm	0.047 "	82 mOhm
Murata Electronics 1286AS-H-R47M=P2	Drum Core Wirewound	Surface Mount	470 nH	0806 (2016 Metric)		Shielded	1 MHz	1.6 mm	0.079 in	0.063 "	2 mm	0806 (2016 Metric)	20 %	Iron Powder	3.4 A	85 °C	-40 C	1.2 mm	0.047 "
