DS87C530 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC MCU 8BIT 16KB OTP 52TQFP

Part	Program Memory Size	Speed	Supplier Device Package	RAM Size	Core Processor	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Program Memory Type	Connectivity	Core Size	Number of I/O	Oscillator Type	Mounting Type	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package [y]	Supplier Device Package [x]	Peripherals
Analog Devices Inc./Maxim Integrated DS87C530-ECL	16 KB	33 MHz	52-TQFP (10x10)	1K x 8	8051	4.5 V	5.5 V	OTP	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-TQFP	0 °C	70 °C
Analog Devices Inc./Maxim Integrated DS87C530-ENL	16 KB	33 MHz	52-TQFP (10x10)	1K x 8	8051	4.5 V	5.5 V	OTP	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-TQFP	-40 ¯C	85 C
Analog Devices Inc./Maxim Integrated DS87C530-KCL	16 KB	33 MHz	52-CLCC	1K x 8	8051	4.5 V	5.5 V	EPROM UV	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-CLCC Window (J Lead)	0 °C	70 °C	19.2	19.2
Analog Devices Inc./Maxim Integrated DS87C530-QCL+	16 KB	33 MHz	52-PLCC (19.13x19.13)	1K x 8	8051	4.5 V	5.5 V	OTP	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-LCC (J-Lead)	0 °C	70 °C
Analog Devices Inc./Maxim Integrated DS87C530-QNL+	16 KB	33 MHz	52-PLCC (19.13x19.13)	1K x 8	8051	4.5 V	5.5 V	OTP	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-LCC (J-Lead)	-40 ¯C	85 C			Power-Fail Reset PWM WDT
Analog Devices Inc./Maxim Integrated DS87C530-QNL	16 KB	33 MHz	52-PLCC (19.13x19.13)	1K x 8	8051	4.5 V	5.5 V	OTP	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-LCC (J-Lead)	-40 ¯C	85 C
Analog Devices Inc./Maxim Integrated DS87C530-QCL	16 KB	33 MHz	52-PLCC (19.13x19.13)	1K x 8	8051	4.5 V	5.5 V	OTP	EBI/EMI SIO UART/USART	8-Bit	32	External	Surface Mount	52-LCC (J-Lead)	0 °C	70 °C
