395-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 28POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Type | Features | Color | Mounting Type | Read Out | Contact Finish | Number of Positions | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Flange Feature | Number of Positions/Bay/Row | Pitch | Pitch | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | Card Guides | Black | Through Hole | Single | Gold | 28 | Non Specified - Single Edge | -40 C | 105 ░C | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 28 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Black | Right Angle Through Hole | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder | Flush Mount Top Opening Unthreaded | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 3.25 mm | 0.128 " | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Black | Through Hole | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 3.25 mm | 0.128 " | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Card Extender | Black | Board Edge Straddle Mount | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder Eyelet(s) | 4-40 Threaded Insert Top Mount Opening | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Card Guides | Black | Through Hole | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Card Extender | Black | Board Edge Straddle Mount | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder Eyelet(s) | M3 Threaded Insert Top Mount Opening | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | Black | Through Hole | Single | Gold | 28 | Non Specified - Single Edge | -40 C | 105 ░C | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 28 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Black | Through Hole | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder | Side Mount Opening Unthreaded | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 3.25 mm | 0.128 " | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Card Extender Card Guides | Black | Board Edge Straddle Mount | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Card Extender | Black | Board Edge Straddle Mount | Dual | Gold | 28 | Non Specified - Dual Edge | -40 C | 105 ░C | Solder Eyelet(s) | Floating Bobbin Top Mount Opening | 14 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | 2 | 2.95 mm | 0.116 " | 2 |
