PN14 Series

Catalog

FORK / SPADE TONGUE TERMINAL, REEL SMART SERIES, 16AWG TO 14AWG, 2.5 MM², M4, #8

Part	Insulation Diameter [Max] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Min] [diameter]	Insulation Diameter [Max] [diameter]	Material - Insulation	Tongue Inside Opening [x]	Tongue Inside Opening [x]	Features	Termination	Terminal Type	Wire Gauge [Min]	Wire Gauge [Max]	Insulation	Mounting Type	Contact Finish	Length - Overall [x]	Length - Overall [x]	Width - Outer Edges [x]	Width - Outer Edges [x]	Contact Material	Stud/Tab Size	Color	Insulation Diameter [diameter]	Insulation Diameter [diameter]	Thickness	Thickness	Length - Overall	Length - Overall	Width - Outer Edges [x]	Tongue Inside Opening	Width - Outer Edges	Width - Outer Edges
Panduit Corp PN14-8LF-3K	0.162 "	0.08 in	2.03 mm	4.11 mm	Nylon Polyamide (PA)	4.06 mm	0.16 in	Serrated Termination	Crimp	Snap Spring	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	23.37 mm	0.92 in	7.37 mm	0.29 in	Copper	8 Stud	Blue
Panduit Corp PN14-8LF-C					Nylon Polyamide (PA)	4.06 mm	0.16 in	Serrated Termination	Crimp	Snap Spring	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	23.37 mm	0.92 in	7.37 mm	0.29 in	Copper	8 Stud	Blue	4.11 mm	0.162 in
Panduit Corp PN14-14R-C	0.162 "	0.08 in	2.03 mm	4.11 mm	Nylon Polyamide (PA)				Crimp	Circular	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	26.67 mm	1.05 in	11.68 mm	0.46 in	Copper	0.25 Stud	Blue			0.76 mm	0.03 in
Panduit Corp PN14-10LF-M					Nylon Polyamide (PA)	4.83 mm	0.19 in	Serrated Termination	Crimp	Snap Spring	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin			8.38 mm	0.33 in	Copper	10 Stud	Blue	4.11 mm	0.162 in			0.91 in	23.11 mm
Panduit Corp PN14-10LFN-M					Nylon Polyamide (PA)	4.83 mm	0.19 in	Serrated Termination	Crimp	Snap Spring	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin			7.11 mm		Copper	10 Stud	Blue	4.11 mm	0.162 in			0.91 in	23.11 mm	0.28 in
Panduit Corp PN14-6LFW-C					Nylon Polyamide (PA)		0.14 in	Serrated Termination	Crimp	Snap Spring	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	21.84 mm	0.86 "	7.37 mm	0.29 in	Copper	6 Stud	Blue	4.11 mm	0.162 in						3.56 mm
Panduit Corp PN14-10R-3K					Nylon Polyamide (PA)			Serrated Termination	Crimp	Circular	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	21.84 mm	0.86 "			Copper	10 Stud	Blue	4.11 mm	0.162 in	0.79 mm	0.031 in					7.87 mm	0.31 in
Panduit Corp PN14-8R-3K					Nylon Polyamide (PA)			Serrated Termination	Crimp	Circular	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	21.84 mm	0.86 "			Copper	8 Stud	Blue	4.11 mm	0.162 in	0.79 mm	0.031 in					7.87 mm	0.31 in
Panduit Corp PN14-10LFN-C					Nylon Polyamide (PA)	4.83 mm	0.19 in	Serrated Termination	Crimp	Snap Spring	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin			7.11 mm		Copper	10 Stud	Blue	4.11 mm	0.162 in			0.91 in	23.11 mm	0.28 in
Panduit Corp PN14-56R-M	0.162 "	0.08 in	2.03 mm	4.11 mm	Nylon Polyamide (PA)				Crimp	Circular	14 AWG	16 AWG	Insulated	Free Hanging (In-Line)	Tin	26.67 mm	1.05 in	11.68 mm	0.46 in	Copper	0.3125 Stud	Blue			0.76 mm	0.03 in
