PEM2-S15 Series
Manufacturer: CUI Inc.
Beta
⌘K
MODULE DC-DC 15VIN 1-OUT 5V 0.4A 2W 4-PIN SIP MODULE
| Part | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Voltage - Input (Max) [Max] | Package / Case | Voltage - Output 1 | Features | Mounting Type | Voltage - Isolation | Voltage - Input (Min) [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Outputs | Current - Output (Max) [Max] | Type | Power (Watts) | Applications | Current - Output (Max) | Current - Output (Max) | Efficiency | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 0.39 " | 0.28 in | 19.6 mm | 7 mm | 0.77 in | 10 mm | 16.5 V | 7-SIP Module 4 Leads | 5 V | SCP | Through Hole | 3000 V | 13.5 V | -40 C | 105 ░C | 1 | 400 mA | Isolated Module | 2 W | ITE (Commercial) | ||||
 CUI Inc. | 0.32 " | 0.39 in | 20.1 mm | 9.9 mm | 0.79 " | 8.2 mm | 16.5 V | 14-DIP Module 6 Leads | 15 V | SCP | Through Hole | 3000 V | 13.5 V | -40 C | 105 ░C | 2 | Isolated Module | 2 W | ITE (Commercial) | 67 mA | 67 mA | 85 % | -15 V |
