630W2W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 2POS R/A SLDR
| Part | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Color | Contact Material | Shell Material, Finish | Ingress Protection | Number of Rows | Contact Finish | Termination | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature | Current Rating (Amps) | Material Flammability Rating | Mounting Type | Shell Size, Connector Layout | Contact Type | Features | Connector Type | Number of Positions | Connector Style | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 30 Áin | 0.76 Ám | Housing/Shell | 4-40 | 30 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Mounting Brackets Shielded | Receptacle Female Sockets | 2 | Combo D-Sub | |
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 30 Áin | 0.76 Ám | Housing/Shell (M3) | 20 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Shielded | Receptacle Female Sockets | 2 | Combo D-Sub | ||
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 15 µin | 0.38 µm | Housing/Shell | 4-40 | 20 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Mounting Brackets Shielded | Receptacle Female Sockets | 2 | Combo D-Sub | |
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 5 µin | 0.127 µm | Housing/Shell (M3) | 10 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Board Lock Mounting Brackets Shielded | Plug Female Sockets and Male Pins | 2 | Combo D-Sub | ||
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 15 µin | 0.38 µm | Housing/Shell (M3) | 40 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Board Lock Mounting Brackets Shielded | Receptacle Female Sockets | 2 | Combo D-Sub | ||
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 5 µin | 0.127 µm | Housing/Shell (M3) | 10 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Board Lock Mounting Brackets Shielded | Receptacle Female Sockets | 2 | Combo D-Sub | ||
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | Housing/Shell | 4-40 | 20 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Shielded | Plug Female Sockets and Male Pins | 2 | Combo D-Sub | Flash | ||
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 5 µin | 0.127 µm | Housing/Shell | 4-40 | 30 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Board Lock Mounting Brackets Shielded | Plug Female Sockets and Male Pins | 2 | Combo D-Sub | |
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | 30 Áin | 0.76 Ám | Housing/Shell | 4-40 | 40 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Shielded | Receptacle Female Sockets | 2 | Combo D-Sub | |
 EDAC Inc. | 125 VDC | -55 C | 125 °C | Polybutylene Terephthalate (PBT) Glass Filled | Black | Copper Alloy | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 1 | Gold | Solder | Housing/Shell | 4-40 | 20 A | UL94 V-0 | Panel Mount Right Angle Through Hole | 1 (DE E) 2V2 2W2 2W2C 2WK2 | Power | Board Lock Mounting Brackets Shielded | Plug Female Sockets and Male Pins | 2 | Combo D-Sub | Flash |
