6356 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 8COND 24AWG SHLD
| Part | Shield Material | Shield Coverage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Wire Gauge | Cable Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Ratings | Features | Number of Conductors [custom] | Conductor Material | Length | Length | Jacket Color | Shield Type | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Conductor Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum Copper Tinned | 65 % 100 % | 0.282 in | 7.16 mm | Poly-Vinyl Chloride (PVC) | 24 AWG | Multi-Conductor | 0.035 in | 0.889 mm | UL Style 2919 | Drain Wire | 8 | Copper Tinned | 304.8 m | 1000 ft | Slate | Braid Foil | 7 | 32 AWG | 300 VDC | 80 °C | -20 ░C | Foam Polyethylene (FPE) |
