R5F526 Series

Manufacturer: Renesas Electronics Corporation

Catalog

Catalog

32BIT MCU RX26T 512K LFQFP100 -4

...

Part	Data Converters [custom]	Data Converters [custom]	Program Memory Type	Mounting Type	Peripherals	Supplier Device Package	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Core Size	Package / Case	Speed	Connectivity	Oscillator Type	Number of I/O [custom]	Program Memory Size	Operating Temperature [Max]	Operating Temperature [Min]	Core Processor	EEPROM Size	RAM Size	Number of I/O	Data Converters
Renesas Electronics Corporation R5F526TFBDFP#10	2 22	12	FLASH	Surface Mount	DMA LVD POR PWM WDT	100-LFQFP (14x14)	5.5 V	2.7 V	32-Bit	100-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal	82	512 KB	85 °C	-40 C	RXv3	16 K	64 K
Renesas Electronics Corporation R5F526TFDDFP#50	2 22	12	FLASH	Surface Mount	DMA LVD POR PWM WDT	100-LFQFP (14x14)	5.5 V	2.7 V	32-Bit	100-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal	82	512 KB	85 °C	-40 C	RXv3	16 K	64 K
Renesas Electronics Corporation R5F526TBDDFN#50			FLASH	Surface Mount	DMA LVD POR PWM WDT	80-LFQFP (12x12)	5.5 V	2.7 V	32-Bit	80-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		256 KB	85 °C	-40 C	RXv3	16 K	64 K	62	A/D 19x12b D/A 2x12b
Renesas Electronics Corporation R5F526TFCGFL#50			FLASH	Surface Mount	DMA LVD POR PWM WDT	48-LFQFP (7x7)	5.5 V	2.7 V	32-Bit	48-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		512 KB	105 ░C	-40 C	RXv3	16 K	64 K	37	A/D 10x12b D/A 2x12b
Renesas Electronics Corporation R5F526T8ADFM#10			FLASH	Surface Mount	DMA LVD POR PWM WDT	64-LFQFP (10x10)	5.5 V	2.7 V	32-Bit	64-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		128 KB	85 °C	-40 C	RXv3	16 K		49	A/D 15x12b D/A 2x12b
Renesas Electronics Corporation R5F526T9BDFL#50			FLASH	Surface Mount	DMA LVD POR PWM WDT	48-LFQFP (7x7)	5.5 V	2.7 V	32-Bit	48-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		128 KB	85 °C	-40 C	RXv3	16 K	64 K	37	A/D 10x12b D/A 2x12b
Renesas Electronics Corporation R5F526TACGFM#30			FLASH	Surface Mount	DMA LVD POR PWM WDT	64-LFQFP (10x10)	5.5 V	2.7 V	32-Bit	64-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		256 KB	105 ░C	-40 C	RXv3	16 K		49	A/D 15x12b D/A 2x12b
Renesas Electronics Corporation R5F526TFCDFP#10	2 22	12	FLASH	Surface Mount	DMA LVD POR PWM WDT	100-LFQFP (14x14)	5.5 V	2.7 V	32-Bit	100-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal	82	512 KB	85 °C	-40 C	RXv3	16 K	64 K
Renesas Electronics Corporation R5F526TFBGFL#50			FLASH	Surface Mount	DMA LVD POR PWM WDT	48-LFQFP (7x7)	5.5 V	2.7 V	32-Bit	48-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		512 KB	105 ░C	-40 C	RXv3	16 K	64 K	37	A/D 10x12b D/A 2x12b
Renesas Electronics Corporation R5F526TACDFM#10			FLASH	Surface Mount	DMA LVD POR PWM WDT	64-LFQFP (10x10)	5.5 V	2.7 V	32-Bit	64-LQFP	120 MHz	CANbus I2C SCI SPI UART/USART	Internal		256 KB	85 °C	-40 C	RXv3	16 K		49	A/D 15x12b D/A 2x12b
