CD2425 Series

Catalog

SSR RELAY SPST-NO 25A 24-280V

Part	Termination Style	Voltage - Input [Max]	Voltage - Input [Min]	Circuit	Approval Agency	Mounting Type	Load Current	Package / Case	Voltage - Load [Min]	Voltage - Load [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Output Type
Sensata-Crydom CD2425W4U	Screw Terminal	32 VDC	4 V	SPST-NO (1 Form A) x 2	CE cURus TUV	Chassis Mount	25 A	Hockey Puck	24 V	280 V	80 °C	-40 C	AC Zero Cross
Sensata-Crydom CD2425D3VH	Screw Terminal	15 V	4 V	SPST-NO (1 Form A) x 2	CE cURus TUV	Chassis Mount	25 A	Hockey Puck	24 V	280 V	80 °C	-40 C	AC Zero Cross
Sensata-Crydom CD2425W4UH	Screw Terminal	32 VDC	4 V	SPST-NO (1 Form A) x 2	CE cURus TUV	Chassis Mount	25 A	Hockey Puck	24 V	280 V	80 °C	-40 C	AC Zero Cross
Sensata-Crydom CD2425D3U	Screw Terminal	15 V	4 V	SPST-NO (1 Form A) x 2	CE cURus TUV	Chassis Mount	25 A	Hockey Puck	24 V	280 V	80 °C	-40 C	AC Zero Cross
